Huber KISS K20 110-120V 1~ 50/60Hz 2011-0020-98

Thumbnail Filmstrip of Huber KISS K20 110-120V 1~ 50/60Hz 2011-0020-98 Images

    Purchase Huber KISS K20 110-120V 1~ 50/60Hz 2011-0020-98

    Huber KISS K20 110-120V 1~ 50/60Hz 2011-0020-98

    SKU: 2011-0020-98




    Vendor: Huber
    Shipping Weight: 80.00 pounds
    Part Number: huber-2011-0020-98

    Product Documents


    Our Price:   $10,750.00

    Get a Quote


    Huber KISS K20 #2011.0020.98

    Cooling bath thermostats with insulated cooling baths are an economic solution for thermoregulation of objects directly in the thermostat bath. The units are therefore suitable for a number of typical heating and cooling tasks such as sample temperature control, materials testing, quality control, analyses, etc. Cooling circulator operates with natural refrigerants and are therefore offer an environmentally friendly solution to temperature control. In addition, cooling circulators are fitted with automatic refrigeration capacity adjustment, reducing energy consumption and waste heat down to the absolute essential. With low level protection and adjustable over heating protection the units fulfil the requirements of Safety Class III/FL according to DIN 12876. The thermostats can also be used for externally attached applications using the pump connections at the rear.
     -The new KISS controller combines state-of-the-art technology with simple operation and stylish design. KISS models are suitable for routine tasks in research and industry and are convincing as practice oriented basic equipment. Option: Pt100 sensor connection #10519 to display (not control) e.g. of the process temperature (only available factory fitted, additional charge).

  • KISS temperature controller
  • Bright, large OLED display
  • Simple operation with menu navigation
  • Simultaneous display of setpoint, Tmin, Tmax and actual temperature
  • Status displays for pump, cooling and heating
  • Overtemperature and low level protection
  • Safety class III/FL (DIN 12876)
  • USB and RS232 interfaces
  • Autostart function for power failure
  • 3 colour versions available: grey (standard), blue, red
  • Natural refrigerant

    General information & temperature controller
    Temperature range  -30...200 °C
    Temperature stability ±0.05 °C
    Temperature display  OLED Display
    Alarm message  optical, acoustical
    Controller KISS
    Safety class  III / FL
    Protection class  IP20
    Dimensions (W x D x H) 350 x 555 x 615 mm  |  13.78 x 21.85 x 24.21 inches
    Weight 36 kg  |  79.38 pounds
    Heating / cooling capacity
    Heating capacity  1,5 kW
    Cooling capacity
    20 0 -10 -20  °C
    0,4 0,35 0,27 0,16  kW
    Cooling machine air-cooled
    Refrigerant (ASHRAE, GHS) R290 (A3, H220) (0,072 kg)
    Circulation pump
    Pressure pump max.  14 lpm ; 0.25 bar  |  3.7 gpm ; 3.62 psi
    Suction pump max.  10.5 lpm ; 0.17 bar  |  2.77 gpm ; 2.47 psi
    Pump connection  -- (Option, #19607 )
    Connections
    Digital interface  USB, RS232
    Operating data
    Permissible ambient temp. 5...40 °C
    Bath opening W x D / BD 290 x 329 / 150 mm  |  11.42 x 12.95 / 5.91 inches
    Bath volume  20 Liters  |  5.28 gal
    Power supply 110-120V 1~ 50/60Hz
    Current max. 15 + 5 A
