Branson CPX 2800 Ultrasonic Cleaning Bath w/Digital Timer

Thumbnail Filmstrip of Branson CPX 2800 Ultrasonic Cleaning Bath w/Digital Timer Images

    Purchase Branson CPX 2800 Ultrasonic Cleaning Bath w/Digital Timer

    Branson CPX 2800 Ultrasonic Cleaning Bath w/Digital Timer

    SKU: CPX-952-219R




    Vendor: Branson
    Shipping Weight: 9.00 pounds
    Part Number: branson-CPX-952-219R

    Product Documents


    Our Price:
    $867.559 $913.22
    Sale Savings: $45.661

    Get a Quote


    Branson CPX 2800 Ultrasonic Cleaning Bath w/Digital Timer

    Bransonic CPX ultrasonic baths feature digital controls with power tracking capabilities to adjust for light or heavy loads, high/low power control, degassing and sleep mode.

    Degassing and conditioning the solution: The CPXH degassing period can be set up to 99 minutes. Extended degas time periods allow for “beyond cleaning” applications such as sample preparation, which includes degassing liquids, mixing and homogenization, dissolving solids, cell lysing, and dispersion of particles.

    Constant activity/power tracking automatically maintains the same ultrasonic power by adjusting for changes in liquid level and temperature caused by a light or heavy load. This helps ensure more uniform cleaning and consistent performance, even with multiple users or when bath conditions change. – Automatic ultrasonic activation: When the process temperature reaches the programmable set point, the ultrasonic cycle begins. This includes selectable times for both degas and ultrasonic processing.

    High/low power control: When cleaning delicate parts, the CPXH allows the user to lower the amplitude of the acoustic energy in the bath: 100% power to the tank for normal applications, 70% power for delicate applications. Manipulating the output waveform in this manner greatly helps to avoid damage to the components in the bath during the ultrasonic process.

    Features:

  • Sweep frequency eliminates standing waves and creates consistent cavitation throughout the tank.
  • 40 kHz rugged industrial transducers>
  • 99-minute digital timer and continuous ultrasonic operation.
  • Last stored parameters are recalled when unit is turned back on.
  • High-temp safety alarm indicator for protection from unit overheating.
  • Controls are located above and behind the cleaning tank in an easily accessible control tower panel, and raised above the tank to avoid damage from cleaning solutions.
  • Convenient built-in pour drains are featured on .5- and .75-gallon models. Tank drains with valves are incorporated on models 1.5-gallon and larger.
  • Plastic body, chemical-resistant

    Specifications:

    Tank Capacity 2.8 Liters / 0.75 Gallons
    Overall Size 13.3"L x 12"W x 11.9"D
    Tank Size 9.5"L x 5.5"W x 4"D
    Weight 9 lbs
    Frequency 40 kHz
    Drain Yes
